Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position

Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position

  • Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position
Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position
Thông tin chi tiết sản phẩm:
Nguồn gốc: Trung Quốc
Hàng hiệu: BRANDO
Chứng nhận: None
Số mô hình: 4V230C-08
Thanh toán:
Số lượng đặt hàng tối thiểu: 300 chiếc
Giá bán: Có thể đàm phán
chi tiết đóng gói: Hộp bên trong, thùng carton, pallet
Thời gian giao hàng: đàm phán
Điều khoản thanh toán: T/T, Công Đoàn Phương Tây, MoneyGram
Khả năng cung cấp: 100000 chiếc mỗi tháng
Tiếp xúc
Chi tiết sản phẩm
Kích thước cổng: Vào=Ra=1/4'', Xả=1/8'' Phạm vi áp suất: 0,15 đến 0,8MPa (21 đến 114PSI)
Vật liệu cơ thể: Hợp kim nhôm Loại van: Đường 5/3, điện từ đôi
Chịu áp lực tối đa: 1.5MPa (215PSI) Max. tối đa. Frequency Tính thường xuyên: 5 chu kỳ / giây
Điện áp: 220V xoay chiều, 110V xoay chiều, 24V xoay chiều, 24V một chiều, 12V một chiều
Làm nổi bật:

Airtac 4V230C08FT Solenoid Air Valve

,

Airtac 4V230C-08 Solenoid Air Valve

,

Solenoid Valve 4V230C-08 for AirTAC

Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position


Pneumatic solenoid valves can be found in a wide range of industries. They are used in Pneumatic Artificial Muscles (PAM) for robotics and automation. Manufacturing companies that use conveyors belts uses pneumatic valves in their conveyor belt systems. Food and beverage manufacturers use them to make, dispense or preserve food and beverage products.


BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.


Data of 4V200 Series Pneumatic Solenoid Valves:

Model
4V210-06
4V220-06
4V230C-06
4V230E-06
4V230P-06
4V210-08
4V220-08
4V230C-08
4V230E-08
4V230P-08
Fluid
Air (to be filtered by 40 μ m filter element)
Acting
Internal Pilot
Port Size
In=Out=Exhaust=1/8''
In=Out=1/4'', Exhaust=1/8''
Orifice Size
25.00 mm2 (Cv=0.78)
18.00 mm2 (Cv=0.67)
30.00 mm2 (Cv=0.89)
18.00 mm2 (Cv=0.67)
Valve Type
5 way 2 position
5 way 3 position
5 way 2 position
5 way 3 position
Working Pressure
0.15~0.8MPa (21~114psi)
Max. Pressure Resistance
1.5MPa (215psi)
Temperature
5~50 ℃
Material of Body
Aluminum Alloy
Max. frequency
5 cycle/sec


Dimension of 4V230C-08 Pneumatic Solenoid Valve:

Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position 0


Product Video of 4V230C-08 Pneumatic Solenoid Valve:



Production Video of Pneumatic Solenoid Valves:



More Pneumatic Products for you to choose:

Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position 1Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position 2Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position 3Pneumatic Solenoid Air Valve 4V230C-08 12V/24V/110V/220V 5 Way 3 Position 4

      Solenoid Operator                                 Manifold                                    Silencer                        Pneumatic Hose Fittings




Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
