CKD Type Coil AB410 Plastic Solenoid Valve Coil Inner Hole 16mm 220V 24V

CKD Type Coil AB410 Plastic Solenoid Valve Coil Inner Hole 16mm 220V 24V

  • CKD Type Coil AB410 Plastic Solenoid Valve Coil Inner Hole 16mm 220V 24V
  • CKD Type Coil AB410 Plastic Solenoid Valve Coil Inner Hole 16mm 220V 24V
CKD Type Coil AB410 Plastic Solenoid Valve Coil Inner Hole 16mm 220V 24V
Thông tin chi tiết sản phẩm:
Nguồn gốc: NINGBO, TRUNG QUỐC
Hàng hiệu: BRANDO
Chứng nhận: None
Số mô hình: BB16039001
Thanh toán:
Số lượng đặt hàng tối thiểu: 200
Giá bán: Có thể đàm phán
chi tiết đóng gói: Hộp bên trong, thùng carton, pallet
Thời gian giao hàng: đàm phán
Điều khoản thanh toán: T/T, PayPal, Western Union
Khả năng cung cấp: 250000 mảnh mỗi tháng
Tiếp xúc
Chi tiết sản phẩm
Tên sản phẩm: Cuộn van điện từ Điện áp: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Quyền lực: 26VA, 18W Sự liên quan: DIN43650A
Mã đặt hàng: AB410 Lớp cách nhiệt: F, h
Lớp bảo vệ: IP65 Đường kính lỗ cuộn: 16mm
Làm nổi bật:

CKD coil plastic coil AB410

,

AB410 Solenoid Valve Coil

,

CKD Coil AB410

CKD Type Coil AB410 Plastic Solenoid Valve Coil Inner Hole 16mm 220V 24V




This solenoid coil is popularly used in water solenoid valves, like 2W040-10, 2W160-15, 2W200-20, 2W250-25, 2S040-10, 2S160-15, 2S200-20, 2S250-25. Voltage: 220VAC, 110VAC, 24VAC, 24VDC, 12VDC, Power: 26VA, 18W. Solenoid valves consist of a coil, plunger and sleeve assembly. Solenoid valves are the most frequently used control elements in fluidics. They are commonly used to shut off, release, dose, distribute or mix fluids. For that reason, they are found in many application areas.


Dimension & Data of Water Solenoid Valve Coil, Armature:

ab410 dimension

BRANDO Model
BB16039001
Voltage

12VDC, 24VDC,

24VAC, 110VAC, 220VAC

Power
26VA, 18W
Other voltage and power can be customized
Insulation Class
F, H
Connector
DIN43650A



ab410 armature dimension

BRANDO Model
BAPC216038501
2 Way or 3 Way
2 Way
NC or NO
NC
Plunger Tube Material
Stainless Steel
Moving Core Material
430FR
Shading Ring Material
Copper
Seal Material
NBR, EPDM, FKM
Mounting Type
Thread


Video of Coil For Water Solenoid Valve:


BRANDO Solenoid Valve Coils Production Video:


More Solenoid Valves for you to choose:

Water Solenoid Valve Core Tube And Plunger Armature Assembly 2 Water Solenoid Valve Core Tube And Plunger Armature Assembly 3 Water Solenoid Valve Core Tube And Plunger Armature Assembly 4
Brass Solenoid Valve Stainless Steel Solenoid Valve Plastic Solenoid Valve


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
